PROGAS LPG SD

SUCTION & DELIVERY HOSE FOR LPG

KEY FEATURES
• Hardwall suction & delivery structure
• Compact, lightweight and flexible
• Robust hose structure for longer life in severe applications
• Long length assemblies available – Max length: 40m (DN12 – DN19) / 50m (DN25 – DN 51) / 61m (DN 63 – DN 102)

APPLICATIONS & FLUIDS
• Suction & delivery hose for LPG

CONTINUOUS SERVICE TEMPERATURE RANGE
-30 °C, -22 °F
70 °C, 158 °F

TUBE
Black NBR conductive rubber

REINFORCEMENT
High tensile synthetic cord and steel helix body wire

COVER
Black, pin-pricked CR rubber, fire-proof, anti-static (R<106 Ohm/m), oil, abrasion and weathering resistant

APPLICABLE SPECS
EN 1762 Type D / TRbF

STANDARD PACKAGING
Coil
